Product Details

With award winning Swedish technology, the dual input D250SE which has now replaced the D250SA  with added connection to lithium batteries can draw its power from smart alternators and other DC sources, making it the ideal charger for vehicles that don’t have access to a mains power supply. Its dual input capability means it can draw power from solar and windsources, in parallel to the alternator.

The D250SE is a fully automatic, 5 step charger that suppliesup to 20A of power to charge, condition and maintain any 12V lead acid service battery from 40-300Ah, including Wet, MF, Gel, AGM.EFB and Ca/Ca & lifepo4 Lithium.

The D250SE uses patented technology so it’s safe for you andyour vehicle’s electronics. It’s also IP65 classified splash anddust proof, and suitable for outdoor use and comes with a 2-yearwarranty.

FASTERCHARGING

The D250SE automatically delivers the optimum charge soyour batteries are fully charged in the shortest possible time.You can select normal or 14.7V AGM charge voltages. It also has a temperature sensor to compensate for hot or cold conditions and avoid the risk of your battery overheating or overcharging.

DIRECT CONNECTION FOR SOLAR POWER

The D250SE has an input for connecting solar panels without the need for a regulator. It also features a Maximum Power Point Tracker (MPPT) to get the maximum power out of your solarpanels.

SMART ALTERNATOR COMPATIBILITY

Vehicle manufacturers are now introducing smart ECU (Engine Control Unit) controlled alternators to increase fuel efficiency and lower emissions. Smart alternators deliver a variable out-put and areshut off when they’re not needed.

The D250SE will still operate even if the smart alternator is shut off and maintain a stable output of up to 20A to fully charge your battery in the shortest time.

Specifications + Parts List

FEATURES

• 5step charging from smart and conventional alternators and DC sources, such as solar and wind

• Automatic battery separator works without the need for diodes or VSR relays

• Selectable AGM mode for AGM batteries

• Parallel input from both alternator and solar panel

• Solar panel regulator with Maximum Power Point Tracking (MPPT)

• Starter battery maintenance charging when your service battery is fully charged

Additional Solar Panel MPPT Information for Ctek D250SE

Max open circuit voltage from panel is only 23v

A higher voltage willdamge the charger and will invalidate warranty
